    ZC450F Fully Automatic Edge Banding Machine Wood Auto Edge Bander 60mm

    ZC450F China Full Automatic edge banding machine


    Can choose manual knife adjustment, pneumatic knife touch screen pneumatic knife clamping style.

    Applicable products: solid wood panels, fibreboard, particleboard, MDF and other panels and other panel furniture Edge. Edge of the main PVC, polyester, melamine and wood, and so on.
    Achieve results: a high degree of automation, high efficiency, high precision and high aesthetics.
    Structural advantages: laser cutting steel plate base, a welded body made of solid deformation does not increase the stability of the machine to ensure that each processing department can work fine. Processing components imported motor and high- quality electrical components.


    Technical Parameters

    Working thickness10-60mm
    Min. working width≥60mm
    Min. panel length≥160mm
    Feeding speed18-24m/min
    Tape thickness0.4-3mm
    Air pressure0.6Mpa
    Total power16.8KW
    Voltage380v,50hz, 3phase
    Power of main drive motor3.7KW
    Weight3000kg
    Overall size6800*1100*1600mm
